PPR Pipes and Fittings

Wavin Vectus PPR pipes and fittings are manufactured using Polypropylene Random Copolymer (PP-RC), which is the most reliable polymer in the piping system industry. The superior physical characteristics of PPR Pipes such as having a working temperature from -20° C to 95°C, along with excellent chemical resistance, providing a definite solution to oxidation and calcification, make Wavin Vectus PPR Piping Systems ideal primarily for chemical transportation, in pharmaceutical companies and for other industrial use, as well as, hot & cold water plumbing systems in buildings and industrial piping.

Due to the high level of strength and light weight, Wavin Vectus PPR Pipes and fittings proves to be the most trusted piping system to be employed in industrial applications and water supply (hot and cold).

Wavin Vectus PPR pipes are the first of its kind 3-layer pipes with-

UV-stabilized outer layer
PP-RC middle layer
Anti-microbial inner layer

The physio-chemical features of Polypropylene Random Copolymer and the type of welding carried out - fusion welding - ensures that the piping system maintains a perfect seal even under the most difficult conditions, which makes it suitable to be used for various other systems like air distribution, radiator heating, etc. Wavin Vectus PPR Piping System is physically superior, hygienically safe, and non-carcinogenic.

PPR Pipes are manufactured as per IS 15801 and are available in PN 6, PN 10, PN 16 & PN 20.

The available range of PPR pipes and fittings vary from 16 mm to 160 mm and is available in 2 different colors -White and Green in length starting from 3, 4, and 6 meters.

Applications

Piping system for the transportation of aggressive fluids in industries
Pharmaceuticals
The compressed air supply system
Transportation of drinking water and liquid food
Indoor as well as outdoor hot & cold water piping system
Solar water heating systems
The heating system inside buildings including floor, wall, and radiator heating

PPR Piping System

Features

Wavin Vectus PPR pipes are the first of its kind 3-layer pipes with-
- UV-stabilized outer layer
- PP-RC middle layer
- Anti-microbial inner layer
PPR Pipes and PPR fittings are non-corrosive, leakproof and frost proof.
Wavin Vectus PPR Piping Systems can endure high impact and pressure, which minimizes structural damages like a diametric contraction.
Wavin Vectus PPR Piping System can easily last up to 50 years without any servicing requirements.
PPR Pipes have a smooth inner surface, thus, reducing the operational pressure required by the motor pump.
PPR is resistant to high temperatures; up to 95°C.
PPR piping systems are heat preserving and energy saving.
Wavin Vectus PPR and Fittings have a smooth inner surface and are scale-free, hence, odor-free.
PP-RC material can work in both acidic and basic solutions; hence shows no reaction with salts and acids.
Its UV stabilized, which prevents the sun rays to degrade or destruct the material resulting in long operational life.

Video

FAQS

What are the different applications of PPR Pipes and fittings?
The most popular uses for Polypropylene (PPR) pipe fittings are in the transportation and handling of liquids.
- Piping system for the transportation of aggressive fluids
- Transportation of drinking water
- Pharmaceutical Industry
- Compressed air supply system
- Heating system inside buildings like radiator heating
- Indoor and outdoor hot & cold water piping system
- Solar water heating systems
What are the unique characteristics of PPR Pipes and Fittings?
- Low Thermal Conductivity:The thermal conductivity of PPR is very low, which means temperature cannot easily be conducted from the outside environment to the liquid in the pipe, and vice versa.
- Lightweight: The density of most plastic materials is usually lower than that of water, but the density of PPR is half that of water. This not only makes transportation conditions better but also reduces the workload during laying and lifting operations.
- Long Service Life Durability: I PPR piping systems can remain functional for over 50 years, at a wide range of fluid and environmental operating temperatures.
- Efficient Inner Surface: The inner surface of PPR pipe and PPR fittings is very smooth and boasts a very low friction coefficient, compared to traditional types of piping.
- Corrosion resistance: PPR pipes and fittings have a low corrosion rate in water environments or when exposed to weathering agents such as atmospheric oxygen and carbon dioxide.
What is the difference between PPR and PVC pipes?

PPR has a higher chemical resistance and wear resistance than PVC. As compared to PVC, PPR exhibits a greater resistance towards UV. PVC and PPR can be used in piping systems that require quick installation and reconfiguration, which requires ruggedness and flexibility. On the flip side, PPR is more expensive than polyvinyl chloride (PVC) due to the cost of raw material and oil needed for production.
What makes Vectus PPR pipes special?
Vectus PPR Pipes are non-corrosive, leakproof and frost proof. They can endure high impact and pressure, which in turn can minimize structural damages. They also have a smooth inner surface which reduces the operational pressure.

Vectus PPR Pipes are the first of its kind 3-layer pipes with-
- UV-stabilized outer layer
- PP-RC middle layer
- Anti-microbial inner layer
Vectus PPR Piping System has a lifespan of 50 years without any servicing requirements.

Size (mm)	Std. Pkg.
32	30
40	20
50	15
63	10
75	6
90	5
110	3 **

Size (mm)	Std. Pkg.
20	75
25	50
32	30
40	20
50	15
63	10
75	6
90	5
110	3

Size (mm)	Std. Pkg.
16	75
20	75
25	50
32	30
40	20
50	15
63	10
75	6
90	5
110	3
160	1

Size (mm)	Std. Pkg.
16	75
20	75
25	50
32	30
40	20
50	15
63	10
75	6
90	5
110	3

Size (mm)	Std. Pkg.
20	30
25	20
32	12
40	8
50	4
63	3
90	1
110	1

Size (mm)	Std. Pkg.
16 X 1/2"	60
20 x 1/2"	60
20 x 3/4"	50
25 x 1/2"	60
25 x 3/4"	40
25 x 1"	20
32 x 1/2"	40
32 x 3/4"	40
32 x 1"	25
32 x 1 1/4"	15
40 x 1"	15
40 x 1 1/4"	15
40 x 1 1/2"	15
50 x 1 1/4"	12
50 x 1 1/2"	12
63 x 2"	1
75 x 2 1/2"	1
90 x 3"	1
110 x 4"	1

Size (mm)	Std. Pkg.
20 x 16	100
25 x 16	100
25 x 20	100
32 x 16	60
32 x 20	60
32 x 25	60
40 x 20	50
40 x 25	50
40 x 32	40
50 x 20	30
50x 25	40
50 x 32	20
50 x 40	20
63 x 32	15
63 x 40	15
63 x 50	10
90 x 32	1
90 x 40	1
90 x 50	1
90 x 63	1
90 x 75	1
110 x 25	1
110 x 32	1
110 x 40	1
110 x 50	1
110 x 63	1
110 x 75	1
110 x 90	1
160 x 75	1
160 x 90	1
160 x 110	1 **

Size (mm)	Std. Pkg.
20 x16 x20	15
25 x 20 x 25	15
32 x 20 x 32	15
32 x 25 x 32	15
40 x 20 x 40	8
40 x 25 x 40	8
40 x 32 x 40	8
50 x 20 x 50	3
50 x 25 x 50	3
50 x 32 x 50	3
50 x 40 x 50	2
63 x 20 x 63	1
63 x 25 x 63	1
63 x 32 x 63	1
63 x 40 x 63	1 **
63 x 50 x 63	1
75 x 25 x 75	1 **
75 x 32 x 75	1
75 x 40 x 75	1 **
75 x 50 x 75	1 **
75 x 63 x 75	1
90 x 32 x 90	1
90 x 40 x 90	1
90 x 50 x 90	1
90 x 63 x 90	1
90 x 75 x 90	1
110 x 25 x 110	1
110 x 32 x 110	1 **
110 x 40 x 110	1
110 x 50 x 110	1
110 x 63 x 110	1
110 x 75 x 110	1
110 x 90 x 110	1
160 x 50 x 160	1
160 x 63 x 160	1 **
160 x 90 x 160	1
160 x 110 x 160	1
